| 브랜드 이름: | OEM |
| 모델 번호: | HY-3DWE |
| MOQ: | 1 |
| 가격: | 협상 가능 |
| Display Mode | 4.3-inch TFT full-color LCD display |
| Measurement Range | ES-08 8mm eddy current sensor: 2.00mm ES-11 11mm eddy current sensor: 4.00mm ES-18 18mm eddy current sensor: 8.00mm ES-25 25mm eddy current sensor: 10.0mm |
| Measurement Accuracy | 0.5 level linear error ≤ 1% FS (full scale) |
| Output Modes | Current output: 4-20mA (load ≤ 1K Ω) RS485 communication: Modbus RTU protocol Secondary switch output: DC30V/5A or AC250V/5A |
| Installation Thread | φ 8mm eddy current sensor: M10 × 1.0mm M14 × 1.5mm eddy current sensor (11mm diameter) 18mm eddy current sensor: M25 × 1.5mm 25mm eddy current sensor: M30 × 2.0mm |
| Operating Environment | Temperature: -40~65℃, Relative humidity: ≤ 95% (non-condensing) |
| Power Supply Voltage | AC85V~265V or DC100V~360V |
