| 브랜드 이름: | OEM |
| 모델 번호: | HY-5VE |
| MOQ: | 1 |
| 가격: | 협상 가능 |
| Measurement Range | Amplitude: 0 to 1000μm (peak-to-peak) Intensity: 0 to 100.0mm/s (true effective value) |
| Frequency Range | 5 to 3000Hz |
| Input Signal | VS series vibration velocity sensors (absolute vibration) ES series eddy current sensors (relative vibration) |
| Measurement Accuracy | Level 0.5, linear error ≤ ±0.5% |
| Display | 4.3-inch TFT true color touch display |
| Output Signals | Current: 4-20mA, load resistance ≤ 850Ω BUF signal for waveform analysis RS485 communication with Modbus RTU protocol Switching output: DC30V/5A or AC250V/5A |
| Operating Environment | Temperature: -40℃ to 65℃ Relative Humidity: ≤ 95% |
| Protection Level | IP56 |
| Power Supply | AC 85V-265V or DC 100V-360V |
