| 브랜드 이름: | ABB |
| 모델 번호: | AO815 |
| MOQ: | 1 |
| 가격: | Negotiations |
| Attribute | Value |
|---|---|
| Signal Specification | 3-wire RTD: Pt100, Cu10, NI100, Ni120 And Resistive Potentiometer |
| Rated Insulation Voltage | 50V |
| Dielectric Test Voltage | 500VAC |
| Current Consumption +5 V Modulebus | 70mA |
| Model Number | DI801 |
| Power Dissipation | 1.6W |
The ABB 3BSE052605R1 is a complete drive system comprising the ACS880-01-0170-3 direct torque control (DTC) drive and P941 mains choke, designed for demanding industrial applications. This 170 kW (228 hp) rated system delivers superior motor control precision, energy efficiency, and power quality management. The ACS880-01 series features ABB's latest generation DTC technology, while the P941 choke provides enhanced harmonic mitigation and power factor correction.
| Parameter | ACS880-01-0170-3 | P941 Mains Choke |
|---|---|---|
| Power Rating | 170 kW (228 hp) | N/A |
| Voltage Range | 3x380-480V AC | N/A |
| Current Rating | 315A | N/A |
| Control Method | Direct Torque Control (DTC) | N/A |
| Frequency Range | 0-500 Hz | N/A |
| Protection Class | IP21 (NEMA 1) | IP00 |
| Cooling Method | Air cooling | N/A |
| Dimensions (HxWxD) | 700x400x450mm | 600x250x350mm |
| Weight | ~110 kg | ~35 kg |
| Harmonic Attenuation | N/A | Up to 70% reduction |
| Power Factor Correction | N/A | Active PFC capability |
| Component | Recommendation |
|---|---|
| Motor | ABB high-efficiency IE4/IE5 motor (matched to 170 kW) |
| Cables | Armored motor cables (15m/20m/25m options) |
| Control Panel | ABB ACS880 control panel with graphical interface |
| Braking | Regenerative braking unit (for frequent stopping applications) |
This premium drive system offers:
