고성능 점화 체계
Created with Pixso.

Boiler high-energy ignition system XDH hard soft rod high energy ignition rdevice

Boiler high-energy ignition system XDH hard soft rod high energy ignition rdevice

브랜드 이름: OEM
모델 번호: XDZ-1
MOQ: 1세트
지불 조건: 티/티
공급 능력: 200
자세한 정보
원래 장소:
중국
전압:
2500V
에너지:
20J
스파크 주파수:
12-14Times /s
프레임 크기:
300*200*120
실:
M18*1.0 M18*1.5 M27*1.5
온도:
1300 ℃
로드 디아:
φ12 、 φ16 、 φ18
포장 세부 사항:
나무 상자 포장
공급 능력:
200
강조하다:

high energy ignition system

,

boiler ignition hard soft rod

,

XDH high performance ignition

제품 설명
Boiler High-Energy Ignition System
XDH Hard & Soft Rod High Energy Ignition Device
Product Description
Portable high-performance ignition system heat box for XDH high-energy ignition device assembly. Compatible with DC 12V and AC 220V power inputs.
This ignition system utilizes ignition cable input voltage DC discharge to generate high-energy electric sparks through the forming head.
Technical Advantages
  • Low ignition voltage requirements
  • Excellent temperature resistance
  • Safety and reliability ensured
  • Strong pollution resistance capability
Applications
Designed for use as XDH high-energy ignition device assembly in industrial boiler systems.
Product Models & Series
Sr. Model Description
1 XDZ-1-l/d Standard type hard rod high energy ignition gun
2 XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun
3 XDZ-1-l/d K Standard type hard gun handle high energy ignition gun
4 XDZ-1R-l/d Standard type soft rod high energy ignition gun
5 XDZ-1R-l/d B Standard type soft rod explosion-proof high-energy igniting gun
6 XDZ-2-l/d Non standard hard rod high energy ignition gun
7 XDZ-2-l/d B Non standard hard rod explosion-proof high-energy igniting gun
8 XDZ-2R-l/d Non standard soft rod high energy ignition gun
9 XDZ-2R-l/d B Non standard soft rod explosion-proof high-energy igniting gun
10 XDZ-3-l/d Special electric nozzle high-energy igniting gun
11 XDZ-3-l/d B Explosion proof special electric nozzle high-energy igniting gun
12 XDZ-4-l/d B The hard rod high clearance point guns
Note:
① In the table, code "l" represents igniting gun length in mm
② In the table, "d" represents igniting gun diameter with 14mm, 16mm, and 18mm series available
③ Custom designs and production available according to user requirements
Outline and Mounting Dimensions
Drawing 3-1: XDZ-1-l/18 Standard type hard rod high energy ignition gun (L≤1000mm)
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  0
Drawing 3-2: XDZ-1-l/18 Standard type hard rod high energy ignition gun (L>1000mm)
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  1
Drawing 3-3: XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  2
Drawing 3-4: XDZ-1-l/18 K Standard type hard gun handle high energy ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  3
Drawing 3-5: XDZ-1R-l/18 Standard type soft rod high energy ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  4
Drawing 3-6: XDZ-3 Catalytic plug ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  5
Drawing 3-7: XDZ-4-l/d hard rod high pressure gap ignition gun
Boiler high-energy ignition system  XDH hard soft rod high energy ignition rdevice  6
