| 브랜드 이름: | Zhong he |
| 모델 번호: | CZJ-4D |
| MOQ: | 1 |
| 가격: | 협상 가능 |
| Parameter | Specification |
|---|---|
| Input Signal | Simultaneous input of four SZ series magnetoelectric velocity sensor signals |
| Measurement Range | Vibration displacement: (0~500) μm (adjustable) Vibration intensity: (0~30.0) mm/s (adjustable) |
| Measurement Accuracy | ±1.0% of full scale (at 25℃) |
| Display | Three-digit LED display Vibration displacement resolution: 1 Vibration intensity resolution: 0.1 |
| Frequency Response | Vibration displacement: (14~100) Hz Vibration intensity: (11~100) Hz |
| Current Output | Active DC (4~20) mA Accuracy: ±1.0% of full scale (at 25℃) Maximum Load: 500Ω |
| Buffer Output | Sensor original signal output (TDM signal) |
| Alarm Settings | Arbitrarily set within full scale range |
| Alarm Output | Relay switch output, normally open contact Resistive load: AC250V/5A, DC28V/5A |
| Alarm Delay | 0.1 seconds, 1 second, 3 seconds (default: 1 second) |
| Operating Environment | Temperature: (0~50)℃ Storage temperature: (-20~60)℃ Relative humidity: (20~90)% (non-condensing) No corrosive environments or strong magnetic fields |
| Power Supply | (85~265)VAC, 50/60Hz |
| Dimensions | 160 mm * 160 mm * 220 mm (W*H*D) |
| Opening Size | 152 mm * 152 mm (W*H) |
| Installation | Panel mounting |
