SMC 2 위치 5방향 파일럿 조작 금속 밀폐 전자기 밸브 VS-7-6-FG-S-B

Name: SMC 2 위치 5방향 파일럿 조작 금속 밀폐 전자기 밸브 VS-7-6-FG-S-B
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: VS-7-6-FG-S-B
Price: 210.00 USD
Availability: InStock

브랜드 이름:	SMC
모델 번호:	VS-7-6-FG-S-B

자세한 정보

제품 설명

자세한 정보

원래 장소:

중국

작동 방법:

파일럿 운영

파일럿 운영:

2자리

항구의 수:

5곳 공항

유체 매체:

공기 / 불활성 가스

운영 압력:

0.1 ~ 1.0 MPa

온도 범위:

5 ~ 60 ° C

전압:

24V AC

전력 소비:

4.5W

유량계수(Cv):

0.15/0.11

강조하다:

5방향 전자기 밸브

소레노이드 밸브 VS-7-6-FG-S-B

파일롯 작동 솔레노이드 밸브

제품 설명

SMC Two position five way pilot operated metal sealed solenoid valve VS-7-6-FG-S-B

Product Name	Two position five way pilot operated metal sealed solenoid valve
Model number	VS-7-6-FG-S-B
Quality	100% brand new original
Warranty	12 months
Package	1 piece

Dimensions of SMC's VS7 series conform to ISO interface sizes 1 and 2. The pilot operated metal seal design allows the valve to be used with non-lube dry air and still maintain a long life. The VS7 is available in 2 or 3 position, double or single action. Manifolds are available with a large variety of functions and piping configurations.

· Size 1, ISO interface solenoid valve

· Fluid: air/inert gas

· Operating pressure: 0.1 to 1.0MPa

· Single or double solenoids

· Options include indicator light, direct manual override, wedge packing style, individual pilot EXH, surge voltage suppressor

VS7-8-FG-S-3A06	VS7-6-FHG-D-2	VS7-6-FG-S-9N(AC110V)
VS7-8-FG-S-3ZA03	VS7-6-FHG-D-2A02	VS7-6-FG-S-9N(AC220V
VS7-8-FG-S-3ZA04	VS7-6-FHG-D-2A03	VS7-6-FG-S-9N(AC220V)
VS7-8-FG-S-5	VS7-6-FHG-D-2B02	VS7-6-FG-S-9NA02
VS7-8-FG-S-5Z	VS7-6-FHG-D-2NA02	VS7-6-FG-S-9NA02(AC220V)
VS7-8-FG-S-6N	VS7-6-FHG-D-2NA03	VS7-6-FG-S-9NA03
VS7-8-FG-S-6NA06	VS7-6-FHG-D-2ZM	VS7-6-FG-S-9NA03(AC110V)
VS7-8-FG-S-6ZA04	VS7-6-FHG-D-2ZMA03	VS7-6-FG-S-9NA03(AC220V)
VS7-8-FG-S-9A06(AC110V)	VS7-6-FHG-D-3	VS7-6-FG-S-9NA03AC220V
VS7-8-FG-S-9N(AC110V)	VS7-6-FHG-D-3A02	VS7-6-FG-S-B
VS7-8-FG-S-9N(AC220V)	VS7-6-FHG-D-3A03	VS7-6-FG-S-BNA03
VS7-8-FG-S-9NA06(AC220V)	VS7-6-FHG	VS7-6-FHG-D-1M
VS7-8-FG-S-9ZA03(AC110V)	VS7-6-FG-S-9A02(AC220V)	VS7-6-FHG-D-1N
VS7-8-FHG-D-2MN	VS7-6-FG-S-9MA03	VS7-6-FHG-D-1NA03
VS7-6-FG-S-2ZM	VS7-6-FG-S-9N	VS7-6-FHG-D-1NM
VS7-6-FG-S-2ZMA03

VS7-6-FG-S-3Z-Q	VS7-6-FG-S-3
VS7-6-FG-S-5	VS7-6-FG-S-3A02
VS7-6-FG-S-5NA03	VS7-6-FG-S-3A03
VS7-6-FG-S-6	VS7-6-FG-S-3MA02
VS7-6-FG-S-6N	VS7-6-FG-S-3MA03
VS7-6-FG-S6NA02	VS7-6-FG-S-3N
VS7-6-FG-S-6NA03	VS7-6-FG-S-3NA02
VS7-6-FG-S-6NMA03	VS7-6-FG-S-3NA03
VS7-6-FG-S-6ZA02	VS7-6-FG-S-3NM
VS7-6-FG-S6ZA03	VS7-6-FG-S-3NMA03
VS7-6-FG-S-9	VS7-6-FG-S-3NMB03
VS7-6-FG-S-9(AC220V)	VS7-6-FG-S-3N-Q
VS7-6-FG-S-9(AC24V)	VS7-6-FG-S-3NX3
VS7-6-FG-S-9A02	VS7-6-FG-S-3Z
VS7-6-FG-S-3ZA03	VS7-6-FG-S-3ZA02
