ABB 전기 모터 M2QA, M3JM QA QABP M3BP 산업 모터 발 / 플랜지 장착

제품 설명:

 ABB 모터최신 기술을 통합하여 신뢰성, 우수한 작동 및 내구성을 보장하는 동시에 모든 구동 응용 분야에 완벽한 모터를 제공합니다. 향상된 성능을 위해 지정된 응용 분야 외에도 각 모터는 고강도 사용을 위한 가장 까다로운 환경을 견딜 수 있습니다.

특징:

M2QA 90S4A-XXX * 3GQA 092101-XXX * 380V50Hz 1.1kW 1385r/분
M2QA 90L4A-XXX * 3GQA 092501-XXX * 380V50Hz 1.5kW 1390r/분
M2QA 100L4A-XXX * 3GQA 102501-XXX * 380V50Hz 2.2kW 1420r/분
M2QA 100L4B-XXX * 3GQA 102502-XXX * 380V50Hz 3kW 1415r/분
M2QA 112M4A-XXX * 3GQA 112301-XXX * 380V50Hz 4kW 1430r/분
M2QA 132S4A-XXX * 3GQA 132101-XXX * 380V50Hz 5.5kW 1425r/분
M2QA 132M4A-XXX * 3GQA 132301-XXX * 380V50Hz 7.5kW 1430r/분
M2QA 160M4A-XXX * 3GQA 162301-XXX * 380V50Hz 11kW 1450r/분
M2QA 160L4A-XXX * 3GQA 162501-XXX * 380V50Hz 15kW 1450r/분
M2QA 180M4A-XXX * 3GQA 182301-XXX * 380V50Hz 18.5kW 1465r/분
M2QA 180L4A-XXX * 3GQA 182501-XXX * 380V50Hz 22kW 1465r/분
M2QA 200L4A-XXX * 3GQA 202501-XXX * 380V50Hz 30kW 1470r/분
M2QA 225S4A-XXX * 3GQA 222101-XXX * 380V50Hz 37kW 1475r/분
M2QA 225M4A-XXX * 3GQA 222301-XXX * 380V50Hz 45kW 1475r/분
M2QA 250M4A-XXX * 3GQA 252301-XXX * 380V50Hz 55kW 1470r/분
M2QA 280S4A-XXX * 3GQA 282101-XXX * 380V50Hz 75kW 1475r/분
M2QA 280M4A-XXX * 3GQA 282301-XXX * 380V50Hz 90kW 1475r/분
M2QA 315S4A-XXX * 3GQA 312101-XXX * 380V50Hz 110kW 1485r/분
M2QA 315M4A-XXX * 3GQA 312301-XXX * 380V50Hz 132kW 1485r/분
M2QA 315L4A-XXX * 3GQA 312501-XXX * 380V50Hz 160kW 1480r/분
M2QA 315L4B-XXX * 3GQA 312502-XXX * 380V50Hz 200kW 1480r/분
M2QA 355M4A-XXX * 3GQA 352301-XXX * 380V50Hz 250kW 1485r/분
M2QA 355L4A-XXX * 3GQA 352501-XXX * 380V50Hz 315kW 1485r/분
M2QA 71M6A-XXX * 3GQA 073301-XXX * 380V50Hz 0.18kW 880r/분
M2QA 71M6B-XXX * 3GQA 073302-XXX * 380V50Hz 0.25kW 880r/분
M2QA 80M6A-XXX * 3GQA 083301-XXX * 380V50Hz 0.37kW 925r/분
M2QA 80M6B-XXX * 3GQA 083302-XXX * 380V50Hz 0.55kW 920r/분
M2QA 90S6A-XXX * 3GQA 093101-XXX * 380V50Hz 0.75kW 915r/분
M2QA 90L6A-XXX * 3GQA 093501-XXX * 380V50Hz 1.1kW 915r/분
M2QA 100L6A-XXX * 3GQA 103501-XXX * 380V50Hz 1.5kW 930r/분
M2QA 112M6A-XXX * 3GQA 113301-XXX * 380V50Hz 2.2kW 935r/분
M2QA 132S6A-XXX * 3GQA 133101-XXX * 380V50Hz 3kW 940r/분
M2QA 132M6A-XXX * 3GQA 133301-XXX * 380V50Hz 4kW 945r/분
M2QA 132M6B-XXX * 3GQA 133302-XXX * 380V50Hz 5.5kW 940r/분
M2QA 160M6A-XXX * 3GQA 163301-XXX * 380V50Hz 7.5kW 950r/분
M2QA 160L6A-XXX * 3GQA 163501-XXX * 380V50Hz 11kW 965r/분
M2QA 180L6A-XXX * 3GQA 183501-XXX * 380V50Hz 15kW 975r/분
M2QA 200L6A-XXX * 3GQA 203501-XXX * 380V50Hz 18.5kW 975r/분
M2QA 200L6B-XXX * 3GQA 203502-XXX * 380V50Hz 22kW 975r/분
M2QA 225M6A-XXX * 3GQA 223301-XXX * 380V50Hz 30kW 980r/분
M2QA 250M6A-XXX * 3GQA 253301-XXX * 380V50Hz 37kW 975r/분
M2QA 280S6A-XXX * 3GQA 283101-XXX * 380V50Hz 45kW 975r/분
M2QA 280M6A-XXX * 3GQA 283301-XXX * 380V50Hz 55kW 975r/분
M2QA 315S6A-XXX * 3GQA 313101-XXX * 380V50Hz 75kW 985r/분
M2QA 315M6A-XXX * 3GQA 313301-XXX * 380V50Hz 90kW 985r/분
M2QA 315L6A-XXX * 3GQA 313501-XXX * 380V50Hz 110kW 985r/분
M2QA 315L6B-XXX * 3GQA 313502-XXX * 380V50Hz 132kW 985r/분
M2QA 450M6A-XXX * 3GQA 453301-XXX * 380V50Hz 160kW 990r/분
M2QA 450M6B-XXX * 3GQA 453302-XXX * 380V50Hz 200kW 990r/분
M2QA 450L6A-XXX * 3GQA 453501-XXX * 380V50Hz 250kW 990r/분
M2QA 80M8A-XXX * 3GQA 084301-XXX * 380V50Hz 0.18kW 695r/분
M2QA 80M8B-XXX * 3GQA 084302-XXX * 380V50Hz 0.25kW 695r/분
M2QA 90S8A-XXX * 3GQA 094101-XXX * 380V50Hz 0.37kW 695r/분
M2QA 90L8A-XXX * 3GQA 094501-XXX * 380V50Hz 0.55kW 695r/분
M2QA 100L8A-XXX * 3GQA 104501-XXX * 380V50Hz 0.75kW 680r/분
M2QA 100L8B-XXX * 3GQA 104502-XXX * 380V50Hz 1.1kW 665r/분
M2QA 112M8A-XXX * 3GQA 114301-XXX * 380V50Hz 1.5kW 690r/분
M2QA 132S8A-XXX * 3GQA 134101-XXX * 380V50Hz 2.2kW 705r/분
M2QA 132M8A-XXX * 3GQA 134301-XXX * 380V50Hz 3kW 705r/분
M2QA 160M8A-XXX * 3GQA 164301-XXX * 380V50Hz 4kW 715r/분
M2QA 160M8B-XXX * 3GQA 164302-XXX * 380V50Hz 5.5kW 715r/분
M2QA 160L8A-XXX * 3GQA 164501-XXX * 380V50Hz 7.5kW 715r/분
M2QA 180L8A-XXX * 3GQA 184501-XXX * 380V50Hz 11kW 725r/분
M2QA 200L8A-XXX * 3GQA 204501-XXX * 380V50Hz 15kW 725r/분
M2QA 225S8A-XXX * 3GQA 224101-XXX * 380V50Hz 18.5kW 735r/분
M2QA 225M8A-XXX * 3GQA 224301-XXX * 380V50Hz 22kW 735r/분
M2QA 250M8A-XXX * 3GQA 254301-XXX * 380V50Hz 30kW 730r/분
M2QA 280S8A-XXX * 3GQA 284101-XXX * 380V50Hz 37kW 735r/분
M2QA 280M8A-XXX * 3GQA 284301-XXX * 380V50Hz 45kW 735r/분
M2QA 315S8A-XXX * 3GQA 314101-XXX * 380V50Hz 55kW 735r/분
M2QA 315M8A-XXX * 3GQA 314301-XXX * 380V50Hz 75kW 735r/분
M2QA 315L8A-XXX * 3GQA 314501-XXX * 380V50Hz 90kW 735r/분
M2QA 315L8B-XXX * 3GQA 314502-XXX * 380V50Hz 110kW 735r/분
M2QA 355M8A-XXX * 3GQA 354301-XXX * 380V50Hz 132kW 740r/분
M2QA 355M8B-XXX * 3GQA 354302-XXX * 380V50Hz 160kW 740r/분
M2QA 355L8A-XXX * 3GQA 354501-XXX * 380V50Hz 200kW 740r/분
M2QA 71M2A-XXX * 3GQA 071301-XXX * 415V50Hz 0.37kW 2790r/분
M2QA 71M2B-XXX * 3GQA 071302-XXX * 415V50Hz 0.55kW 2800r/분
M2QA 80M2A-XXX * 3GQA 081301-XXX * 415V50Hz 0.75kW 2855r/분
M2QA 80M2B-XXX * 3GQA 081302-XXX * 415V50Hz 1.1kW 2870r/분
M2QA 90S2A-XXX * 3GQA 091101-XXX * 415V50Hz 1.5kW 2865r/분
M2QA 90L2A-XXX * 3GQA 091501-XXX * 415V50Hz 2.2kW 2865r/분
M2QA 100L2A-XXX * 3GQA 101501-XXX * 415V50Hz 3kW 2870r/분
M2QA 112M2A-XXX * 3GQA 111301-XXX * 415V50Hz 4kW 2890r/분
M2QA 132S2A-XXX * 3GQA 131101-XXX * 415V50Hz 5.5kW 2910r/분
M2QA 132S2B-XXX * 3GQA 131102-XXX * 415V50Hz 7.5kW 2920r/분
M2QA 160M2A-XXX * 3GQA 161301-XXX * 415V50Hz 11kW 2930r/분
M2QA 160M2B-XXX * 3GQA 161302-XXX * 415V50Hz 15kW 2930r/분
M2QA 160L2A-XXX * 3GQA 161501-XXX * 415V50Hz 18.5kW 2930r/분
M2QA 180M2A-XXX * 3GQA 181301-XXX * 415V50Hz 22kW 2950r/분
M2QA 200L2A-XXX * 3GQA 201501-XXX * 415V50Hz 30kW 2960r/분
M2QA 200L2B-XXX * 3GQA 201502-XXX * 415V50Hz 37kW 2960r/분
M2QA 71M2A-XXX * 3GQA 071301-XXX * 415V50Hz 45kW 2970r/분
M2QA 250M2A-XXX * 3GQA 251301-XXX * 415V50Hz 55kW 2965r/분
M2QA 280S2A-XXX * 3GQA 281101-XXX * 415V50Hz 75kW 2975r/분
M2QA 280M2A-XXX * 3GQA 281301-XXX * 415V50Hz 90kW 2975r/분
M2QA 315S2A-XXX * 3GQA 311101-XXX * 415V50Hz 110kW 2980r/분
M2QA 315M2A-XXX * 3GQA 311301-XXX * 415V50Hz 132kW 2980r/분
M2QA 315L2A-XXX * 3GQA 311501-XXX * 415V50Hz 160kW 2980r/분
M2QA 315L2B-XXX * 3GQA 311502-XXX * 415V50Hz 200kW 2980r/분
M2QA 355M2A-XXX * 3GQA 351301-XXX * 415V50Hz 250kW 2980r/분
M2QA 355L2A-XXX * 3GQA 351501-XXX * 415V50Hz 315kW 2980r/분
M2QA 71M4A-XXX * 3GQA 072301-XXX * 415V50Hz 0.25kW 1405r/분
M2QA 71M4B-XXX * 3GQA 072302-XXX * 415V50Hz 0.37kW 1405r/분
M2QA 80M4A-XXX * 3GQA 082301-XXX * 415V50Hz 0.55kW 1420r/분
M2QA 80M4B-XXX * 3GQA 082302-XXX * 415V50Hz 0.75kW 1425r/분
M2QA 90S4A-XXX * 3GQA 092101-XXX * 415V50Hz 1.1kW 1405r/분
M2QA 90L4A-XXX * 3GQA 092501-XXX * 415V50Hz 1.5kW 1410r/분
M2QA 100L4A-XXX * 3GQA 102501-XXX * 415V50Hz 2.2kW 1435r/분
M2QA 100L4B-XXX * 3GQA 102502-XXX * 415V50Hz 3kW 1430r/분
M2QA 112M4A-XXX * 3GQA 112301-XXX * 415V50Hz 4kW 1440r/분
M2QA 132S4A-XXX * 3GQA 132101-XXX * 415V50Hz 5.5kW 1440r/분
M2QA 132M4A-XXX * 3GQA 132301-XXX * 415V50Hz 7.5kW 1450r/분
M2QA 160M4A-XXX * 3GQA 162301-XXX * 415V50Hz 11kW 1460r/분
M2QA 160L4A-XXX * 3GQA 162501-XXX * 415V50Hz 15kW 1460r/분
M2QA 180M4A-XXX * 3GQA 182301-XXX * 415V50Hz 18.5kW 1470r/분
M2QA 180L4A-XXX * 3GQA 182501-XXX * 415V50Hz 22kW 1470r/분
M2QA 200L4A-XXX * 3GQA 202501-XXX * 415V50Hz 30kW 1475r/분
M2QA 225S4A-XXX * 3GQA 222101-XXX * 415V50Hz 37kW 1480r/분
M2QA 225M4A-XXX * 3GQA 222301-XXX * 415V50Hz 45kW 1480r/분
M2QA 250M4A-XXX * 3GQA 252301-XXX * 415V50Hz 55kW 1480r/분
M2QA 280S4A-XXX * 3GQA 282101-XXX * 415V50Hz 75kW 1485r/분
M2QA 280M4A-XXX * 3GQA 282301-XXX * 415V50Hz 90kW 1485r/분
M2QA 315S4A-XXX * 3GQA 312101-XXX * 415V50Hz 110kW 1485r/분
M2QA 315M4A-XXX * 3GQA 312301-XXX * 415V50Hz 132kW 1485r/분
M2QA 315L4A-XXX * 3GQA 312501-XXX * 415V50Hz 160kW 1485r/분
M2QA 315L4B-XXX * 3GQA 312502-XXX * 415V50Hz 200kW 1485r/분
M2QA 355M4A-XXX * 3GQA 352301-XXX * 415V50Hz 250kW 1490r/분
M2QA 355L4A-XXX * 3GQA 352501-XXX * 415V50Hz 315kW 1490r/분
M2QA 71M6A-XXX * 3GQA 073301-XXX * 415V50Hz 0.18kW 890r/분
M2QA 71M6B-XXX * 3GQA 073302-XXX * 415V50Hz 0.25kW 890r/분
M2QA 80M6A-XXX * 3GQA 083301-XXX * 415V50Hz 0.37kW 935r/분
M2QA 80M6B-XXX * 3GQA 083302-XXX * 415V50Hz 0.55kW 930r/분
M2QA 90S6A-XXX * 3GQA 093101-XXX * 415V50Hz 0.75kW 930r/분
M2QA 90L6A-XXX * 3GQA 093501-XXX * 415V50Hz 1.1kW 925r/분
M2QA 100L6A-XXX * 3GQA 103501-XXX * 415V50Hz 1.5kW 945r/분
M2QA 112M6A-XXX * 3GQA 113301-XXX * 415V50Hz 2.2kW 945r/분
M2QA 132S6A-XXX * 3GQA 133101-XXX * 415V50Hz 3kW 950r/분
M2QA 132M6A-XXX * 3GQA 133301-XXX * 415V50Hz 4kW 955r/분
M2QA 132M6B-XXX * 3GQA 133302-XXX * 415V50Hz 5.5kW 955r/분
M2QA 160M6A-XXX * 3GQA 163301-XXX * 415V50Hz 7.5kW 970r/분
M2QA 160L6A-XXX * 3GQA 163501-XXX * 415V50Hz 11kW 975r/분
M2QA 180L6A-XXX * 3GQA 183501-XXX * 415V50Hz 15kW 980r/분
M2QA 200L6A-XXX * 3GQA 203501-XXX * 415V50Hz 18.5kW 980r/분
M2QA 200L6B-XXX * 3GQA 203502-XXX * 415V50Hz 22kW 980r/분
M2QA 225M6A-XXX * 3GQA 223301-XXX * 415V50Hz 30kW 985r/분
M2QA 250M6A-XXX * 3GQA 253301-XXX * 415V50Hz 37kW 980r/분
M2QA 280S6A-XXX * 3GQA 283101-XXX * 415V50Hz 45kW 985r/분
M2QA 280M6A-XXX * 3GQA 283301-XXX * 415V50Hz 55kW 985r/분
M2QA 315S6A-XXX * 3GQA 313101-XXX * 415V50Hz 75kW 990r/분
M2QA 315M6A-XXX * 3GQA 313301-XXX * 415V50Hz 90kW 990r/분
M2QA 315L6A-XXX * 3GQA 313501-XXX * 415V50Hz 110kW 990r/분
M2QA 315L6B-XXX * 3GQA 313502-XXX * 415V50Hz 132kW 990r/분
M2QA 450M6A-XXX * 3GQA 453301-XXX * 415V50Hz 160kW 990r/분
M2QA 450M6B-XXX * 3GQA 453302-XXX * 415V50Hz 200kW 990r/분
M2QA 450L6A-XXX * 3GQA 453501-XXX * 415V50Hz 250kW 990r/분
M2QA 80M8A-XXX * 3GQA 084301-XXX * 415V50Hz 0.18kW 705r/분
M2QA 80M8B-XXX * 3GQA 084302-XXX * 415V50Hz 0.25kW 705r/분
M2QA 90S8A-XXX * 3GQA 094101-XXX * 415V50Hz 0.37kW 705r/분
M2QA 90L8A-XXX * 3GQA 094501-XXX * 415V50Hz 0.55kW 705r/분
M2QA 100L8A-XXX * 3GQA 104501-XXX * 415V50Hz 0.75kW 695r/분
M2QA 100L8B-XXX * 3GQA 104502-XXX * 415V50Hz 1.1kW 685r/분
M2QA 112M8A-XXX * 3GQA 114301-XXX * 415V50Hz 1.5kW 700r/분
M2QA 132S8A-XXX * 3GQA 134101-XXX * 415V50Hz 2.2kW 715r/분
M2QA 132M8A-XXX * 3GQA 134301-XXX * 415V50Hz 3kW 715r/분
M2QA 160M8A-XXX * 3GQA 164301-XXX * 415V50Hz 4kW 725r/분
M2QA 160M8B-XXX * 3GQA 164302-XXX * 415V50Hz 5.5kW 720r/분
M2QA 160L8A-XXX * 3GQA 164501-XXX * 415V50Hz 7.5kW 720r/분

신청:

ABB 모터는 50Hz 및 60Hz 주파수 모두에서 작동하도록 제작되었습니다. 또한 방수 및 IP55 등급 보호 기능이 제공되어 습기나 먼지에 노출되는 열악한 환경에서 사용하기에 적합합니다. 모터는 발 장착형 및 플랜지 장착형 구성으로 제공되므로 설치 및 작동이 쉽습니다.

ABB MOTOR M3JP 시리즈는 다양한 산업 시나리오에서 사용되는 또 다른 인기 옵션입니다. 이 모터는 높은 출력과 뛰어난 효율성으로 잘 알려져 있습니다. 0.06KW에서 1119KW까지 다양한 크기와 출력으로 제공되므로 광범위한 응용 분야에 적합합니다.

ABB 모터의 일반적인 응용 분야로는 펌프, 압축기, 팬, 컨베이어 및 기타 산업 기계가 있습니다. 이 모터는 높은 성능과 신뢰성이 중요한 제조, 가공, 광업 산업에서 널리 사용됩니다.

3G1C 모델은 자동차 및 항공우주 산업에서 널리 사용되는 또 다른 인기 옵션입니다. 이 모터는 높은 토크와 속도를 제공하도록 설계되어 높은 수준의 정확성과 제어가 필요한 정밀 응용 분야에 사용하기에 이상적입니다.

결론적으로 ABB MOTOR 3상 전기 모터 제품군은 광범위한 산업 응용 분야에 사용할 수 있는 안정적이고 효율적인 솔루션입니다. 낮은 소음 수준, 높은 전력 출력 및 탁월한 효율성을 갖춘 이 제품은 전 세계 엔지니어와 제조업체 사이에서 인기 있는 선택입니다.
